The SDC 2,5 PCB connectors can be connected directly to the PCB via through-contacted bore holes. This is possible without tools or an additional header. The connectors feature Phoenix Contact’s “SKEDD” plug-in technology, for easy PCB mounting.
The geometry of SKEDD contacts is similar to press-in technology. Each contact pin is made up of two flexible halves that easily adjust to plated through-holes on a PCB. When the contact is inserted into a through-hole, the integrated body-bound rivets lock the connectors in place to form a vibration-resistant connection.
Wires can be terminated to the connector with the popular push-in spring connection. Solid and stranded wires with a ferrule can be pushed directly into the terminal block without opening the spring clamp. To remove the wires, the user simply presses the orange spring lever with a standard screwdriver.
Your advantages
•Easy handling thanks to tool-free connection to the PCB
•Smaller number of components and processes reduces production effort
•Vibration-proof connection thanks to locking with body-bound rivets
•User-friendly conductor connection thanks to push-in spring connection with spring opener
In case of interest please contact us at sales@soselectronic.com.
Revolutionary connectors applicable into PCB without soldering.
- Currents: up to 12 A
- Voltages: up to 320 V (300 V UL)
- Conductor cross sections: 0.2 mm² to 2.5 mm²
- Pitch: 5.0 mm
- 1 to 16-pos.
